Libi Technologies : GPS Vehicle Tracking System in India
LT08
LT08
Device Features
  • *Support 2G GSM network
  • *Built-in GSM&GPS antenna
  • *Real time positioning
  • *Historical tracking
  • *Geo-fence In/Out Alarm
  • *ACC detection, exact status
  • *Cut and Restore oil and electric
  • *SOS security alarm
  • *Voice monitoring
  • *Over speed alarm/vibration alarm
  • *GPS/GSM led light: blue and red
  • *Mini size:66*33*10.5mm
  • *Working voltage:9.5V-36V
  • *5000pcs data memory when GPS/GSM not well
Hardware Technical Specification
  • • Network: GSM
  • • Data Service: GPRS
  • • Frequency: GSM:850/900/1800/1900
  • • LED: Blue – GPS, Red-Power, Green-GSM
  • • Switch: ON/OFF
  • • Working: ON/OFF button to control internal battery
  • • G-sensor: Support
  • • SIM Card Slot: One, Micro SIM Card
  • • Wires: Power, GND, Engine Cut, ACC
  • • External Power disconnect alarm: support
  • • External Power connection status detection: support
  • • GSM baseband IC-MTK 6261D
  • • GSM band-850/900/1800/1900MHz
  • • GPRS-Class12
  • • GPS signal-L1,1575.42MHz C/A code
  • • GPS channels-56 channels
  • • GPS fixed Time with AGPS-Cold start 15s ,hot start 2s
  • • GPS receiving sensitivity-Tracking:-159dBm,
  • • Capturing:-143dBm
  • • GPS positioning accuracy-10-15m
  • • Average standby current <2.5mA
  • • Average working current <55mA
  • • Working temperature=-20~+70 centigrade
  • • Working humidity=5% to 95%
  • • GPS ANT-highly sensitive=ANT
  • • GSM ANT-dual band monopole-antenna
  • • ACC Detect Support=Yes
  • • Oil/Power Control Support=Yes
  • • Working Voltage =9V~ 36V
LT08 is designed for customers that simply need 24X7 location information (Tracking) of their fleet or vehicle.
